powder coating ?

mxlifeline
Edited Date/Time 11/14/2015 2:36pm
does anyone have any experience with powder coating rims and hubs? does it look good and is it durable? Most importantly is it worth the time and money or should i just buy some wheels from dubya or warp 9?
|
mb
Profile picture for user mb
Posts
775
Joined
7/22/2014
Location
Columbia, SC, USA
mb 11/12/2015 9:18pm
11/12/2015 9:18pm
I wouldn't do rims but hubs would be fine.
lumpy790
Profile picture for user lumpy790
Posts
11646
Joined
9/18/2007
Location
York, SC, USA
lumpy790 11/13/2015 3:10am
11/13/2015 3:10am
clean, primer and Krylon paint for the hubs. Its not like hubs are a high wear item. I painted my frame too.






WileCyot
Profile picture for user WileCyot
Posts
458
Joined
9/23/2014
Location
Katy, TX, USA
WileCyot 11/13/2015 5:42am
11/13/2015 5:42am
I powder coated this valve cover last night. Hubs would be fine. Don't do the rims. They'll chip.

I'm looking forward to getting in some wrinkle red powder as well.





Charper732
Profile picture for user Charper732
Posts
711
Joined
6/24/2015
Location
Scottdale, GA, USA
Charper732 11/13/2015 6:57am
11/13/2015 6:57am Edited Date/Time 11/13/2015 6:59am
I do my own powder coating but I tell people all the time...If you are PCing or lacing and truing the rims yourself it can be worth it. But if you are paying someone to do those things it is a waist of money. It'll cost you near $400...You can get a set of tusk wheels for ~550 and you'd have an extra set of wheels...

The Shop

See All »
Charper732
Profile picture for user Charper732
Posts
711
Joined
6/24/2015
Location
Scottdale, GA, USA
Charper732 11/13/2015 7:02am
11/13/2015 7:02am Edited Date/Time 11/13/2015 7:03am
WileCyot, I used the wrinkle on the rim. That powder is by FAR the most durable I have ever used. I probably put ~50hrs on the rim before rim scrub started to show on the rear.



shocker yellow over any kinda green or silver looks super sick too.



WileCyot
Profile picture for user WileCyot
Posts
458
Joined
9/23/2014
Location
Katy, TX, USA
WileCyot 11/13/2015 7:12am
11/13/2015 7:12am
Prismatic has some awesome powders. I'm in the process of building an oven big enough to do motorcycle frames.

I am wanting to do my buddies KTM valve cover in this color:



Charper732
Profile picture for user Charper732
Posts
711
Joined
6/24/2015
Location
Scottdale, GA, USA
Charper732 11/13/2015 7:27am
11/13/2015 7:27am
WileCyot wrote:
Prismatic has some awesome powders. I'm in the process of building an oven big enough to do motorcycle frames. I am wanting to do my buddies...
Prismatic has some awesome powders. I'm in the process of building an oven big enough to do motorcycle frames.

I am wanting to do my buddies KTM valve cover in this color:



Is that over a chrome base? I have some anodized blue and red that if you spray it over a chrome base it gives a frosted look similar to that
K-dubbb
Profile picture for user K-dubbb
Posts
472
Joined
12/10/2013
Location
CA
K-dubbb 11/13/2015 7:50am
11/13/2015 7:50am
I did both my rims and hubs, here they are after a season and a lot of pulling tires on and off. Use lots of soap and water and be delicate and they last. Hubs are good for sure.





Markopolo400
Profile picture for user Markopolo400
Posts
1427
Joined
7/24/2012
Location
St. Paul-ish, MN, USA
Markopolo400 11/13/2015 8:11am
11/13/2015 8:11am
What kind of equipment/oven are you guys using for your at home set ups?

When I get space PCing is on my list of at home projects.
WileCyot
Profile picture for user WileCyot
Posts
458
Joined
9/23/2014
Location
Katy, TX, USA
WileCyot 11/13/2015 8:18am
11/13/2015 8:18am
WileCyot wrote:
Prismatic has some awesome powders. I'm in the process of building an oven big enough to do motorcycle frames. I am wanting to do my buddies...
Prismatic has some awesome powders. I'm in the process of building an oven big enough to do motorcycle frames.

I am wanting to do my buddies KTM valve cover in this color:



Charper732 wrote:
Is that over a chrome base? I have some anodized blue and red that if you spray it over a chrome base it gives a frosted...
Is that over a chrome base? I have some anodized blue and red that if you spray it over a chrome base it gives a frosted look similar to that
It's Peeka Blue over Super Chrome with Casper Clear Top Coat.
HackMan162
Profile picture for user HackMan162
Posts
534
Joined
2/16/2007
Location
Austin, TX, USA
HackMan162 11/13/2015 10:04am
11/13/2015 10:04am
I am thinking (possibly wrong) that PC would add significant weight to the rim, which is rotating, unsprung weight. (bad). Have you guys weighed a rim before/after PC? ANodize shouldnt have much effect.
WileCyot
Profile picture for user WileCyot
Posts
458
Joined
9/23/2014
Location
Katy, TX, USA
WileCyot 11/13/2015 11:09am
11/13/2015 11:09am
HackMan162 wrote:
I am thinking (possibly wrong) that PC would add significant weight to the rim, which is rotating, unsprung weight. (bad). Have you guys weighed a rim...
I am thinking (possibly wrong) that PC would add significant weight to the rim, which is rotating, unsprung weight. (bad). Have you guys weighed a rim before/after PC? ANodize shouldnt have much effect.
Anodizing will not increase the weight of rims. That close to the axis of rotation, hub, it will be neglegable. I would worry more about sprung weight.
Charper732
Profile picture for user Charper732
Posts
711
Joined
6/24/2015
Location
Scottdale, GA, USA
Charper732 11/13/2015 5:50pm
11/13/2015 5:50pm
I have never weighed the rims before and after because it is almost nothing. I could powder coat 10 rims with one pound of powder...and keep in mind the majority of that does not get applied to the rim, it falls to the ground.
HackMan162
Profile picture for user HackMan162
Posts
534
Joined
2/16/2007
Location
Austin, TX, USA
HackMan162 11/13/2015 7:51pm
11/13/2015 7:51pm
Yeah, good point. I have just heard horror stories about powder coated frames being 5 lbs heavier than painted ones. I think it might just be an MXA-ism.
Charper732
Profile picture for user Charper732
Posts
711
Joined
6/24/2015
Location
Scottdale, GA, USA
Charper732 11/14/2015 1:18pm
11/14/2015 1:18pm
HackMan162 wrote:
Yeah, good point. I have just heard horror stories about powder coated frames being 5 lbs heavier than painted ones. I think it might just be...
Yeah, good point. I have just heard horror stories about powder coated frames being 5 lbs heavier than painted ones. I think it might just be an MXA-ism.
Yeah...someone made that up. It would be impossible to get that much power to actually stick.
Charper732
Profile picture for user Charper732
Posts
711
Joined
6/24/2015
Location
Scottdale, GA, USA
Charper732 11/14/2015 1:22pm
11/14/2015 1:22pm Edited Date/Time 11/14/2015 1:23pm
Markopolo400 wrote:
What kind of equipment/oven are you guys using for your at home set ups? When I get space PCing is on my list of at home...
What kind of equipment/oven are you guys using for your at home set ups?

When I get space PCing is on my list of at home projects.
I use a spectra coat system. I think it was like $800. For an oven, you can start off using an old house hold oven but you'll soon want to build your own and just use the guts from old home ovens.

The hardest part of PCing is controling the environment you are spraying in, ANY dust in the air and it'll fk up the powder coat. Having a dry air supply is equally important. If your compressor is on very much it will create condensation very quickly and ruin whatever you are spraying.
Premix
Profile picture for user Premix
Posts
1505
Joined
1/5/2014
Location
USA
Premix 11/14/2015 2:11pm
11/14/2015 2:11pm
Charper732 wrote:
I do my own powder coating but I tell people all the time...If you are PCing or lacing and truing the rims yourself it can be...
I do my own powder coating but I tell people all the time...If you are PCing or lacing and truing the rims yourself it can be worth it. But if you are paying someone to do those things it is a waist of money. It'll cost you near $400...You can get a set of tusk wheels for ~550 and you'd have an extra set of wheels...
Those tusk wheels are cheap. And by cheap I mean shit. Broke 5 spokes out of mine in less than 3 rides. Aluminum nips, stock size spokes, cheap alloy rims. Hubs appear to be okay but I made the mistake and tried to save some cash vs. Dubya or A60's on the stock hubs and payed the price.
Charper732
Profile picture for user Charper732
Posts
711
Joined
6/24/2015
Location
Scottdale, GA, USA
Charper732 11/14/2015 2:36pm
11/14/2015 2:36pm Edited Date/Time 11/14/2015 2:36pm
Charper732 wrote:
I do my own powder coating but I tell people all the time...If you are PCing or lacing and truing the rims yourself it can be...
I do my own powder coating but I tell people all the time...If you are PCing or lacing and truing the rims yourself it can be worth it. But if you are paying someone to do those things it is a waist of money. It'll cost you near $400...You can get a set of tusk wheels for ~550 and you'd have an extra set of wheels...
Premix wrote:
Those tusk wheels are cheap. And by cheap I mean shit. Broke 5 spokes out of mine in less than 3 rides. Aluminum nips, stock size...
Those tusk wheels are cheap. And by cheap I mean shit. Broke 5 spokes out of mine in less than 3 rides. Aluminum nips, stock size spokes, cheap alloy rims. Hubs appear to be okay but I made the mistake and tried to save some cash vs. Dubya or A60's on the stock hubs and payed the price.
First I've heard of anyone having problems with them...but I haven't been looking either.

If it makes you feel any better SMPRO just dropped the price on their Platinum wheel set to $875. I haven't had any problems out of mine, but I check spoke tightness regularly
