Posts: 88
Joined: 3/24/2017
Location: Odenton, MD USA
I want to find Titanium pegs for my 07 RM125 and I have seen a few around but I want the new Works Connection one's but they don't offer them for my bike but some have said 2013 ktm 250sx pegs will work. Anybody know if this is entirely true? A few people said this to so it kinda sound like it may work.
Posts: 3733
Joined: 4/1/2008
Location: USA
Posts: 3733
Joined: 4/1/2008
Location: USA
Posts: 88
Joined: 3/24/2017
Location: Odenton, MD USA
Bruce372 wrote:
i modded some late model RMZ-450 pegs on my RM125.
[img]https://flic.kr/p/qFri17[/img]
what year? I heard the RMZ pegs don't fit at all.
Posts: 3733
Joined: 4/1/2008
Location: USA
Those in the picture are torq1 steel pegs from a 2015 rmz450. I bought them, put them on my 450 and realizes they were cheap made in China product that didn't fit right.
They won't bolt straight up to the rm125, I just put them in and slowly filed the stopper until they sit at the right height. The post is 1mm shorter also, but you can shim that with a washer
Posts: 457
Joined: 3/5/2017
Location: Johnson City, TN USA
I've read all over vital that newer ktm pegs fit the rms, I'm curious if the people who run them use the stock Suzuki hardware or if you have to use ktm hardware too.
Posts: 1050
Joined: 3/31/2014
Location: Mackay QLD, AUS
06 RM250's came standard with Titanium footpegs, That year only and only the 250's. They are hard to come by and as far as I remember they share the same part number as the standard steel pegs of different year models, so they are impossible to get unless you got an 06 RM250 new.
KTM footpegs are the same as Suzuki, their OEM from as far back as anybody can remember will go straight on a Suzuki up until at least 2013 year model (not sure about 2014 or newer models).
Instagram @_yabba_dabba_dont_
Posts: 177
Joined: 2/10/2014
Location: Douglas, MA USA
Posts: 747
Joined: 3/29/2016
Location: Ithaca, NY USA
2006 RMs came with Ti pegs. I have the stockers on my 250 and they're pretty nice, could be a little wider tho.
Posts: 101
Joined: 1/17/2017
Location: Rohnert Park, CA USA
I literally just bolted up a set of Propegs 2004-2015 KTM pegs, and they are STELLAR. I did end up using the stock KTM springs (cheap, i think 1.40 a piece), and I ordered a matching KTM Ti pin that bolted up just fine. In my build page there are pretty close up pics of the install.
Hope this helps!
http://www.ebay.com/itm/Pro-Pegs-titanium-footpegs-2004-2015-KTM-SXF-SMR-SXS-EXC-250-300-350-450-525-660-/201415622138?hash=item2ee54e7dfa:g:oGQAAOSwd0BV3smL&vxp=mtr
http://www.vitalmx.com/forums/Bike-Builds,46/Not-another-RM125,1312944?page=3
Posts: 177
Joined: 2/10/2014
Location: Douglas, MA USA
Joyner41 wrote:
I literally just bolted up a set of Propegs 2004-2015 KTM pegs, and they are STELLAR. I did end up using the stock KTM springs (cheap, i think 1.40 a piece), and I ordered a matching KTM Ti pin that bolted up just fine. In my build page there are pretty close up pics of the install.
Hope this helps!
http://www.ebay.com/itm/Pro-Pegs-titanium-footpegs-2004-2015-KTM-SXF-SMR-SXS-EXC-250-300-350-450-525-660-/201415622138?hash=item2ee54e7dfa:g:oGQAAOSwd0BV3smL&vxp=mtr
http://www.vitalmx.com/forums/Bike-Builds,46/Not-another-RM125,1312944?page=3
When i used the Raptor Ti pegs that were made for the KTM i used KTM springs and Yamaha YZ pins cause they are lighter than the RM and KTM pins.
