Kawasaki Kx 250 2006

Related:
Create New Tag

7/28/2017 11:07 AM














|

7/28/2017 11:22 AM











|

7/28/2017 1:19 PM

Great transformation! Had an 07, the pc link does wonders!

|

8/24/2017 6:58 AM

Bike looks great!!

|

8/24/2017 2:55 PM

Cleaned up nice

|

11/20/2017 11:47 AM

Not much progress. New oversized front rotor and crf style mastercylinder. Much better braking and lever feeling. Still a lot to do before its finished


|

12/10/2017 2:31 AM
Edited Date/Time: 12/12/2017 11:57 AM

Made these after work today. blink aluminum 7075 Photo




|

12/11/2017 6:55 AM

Bachmx468 wrote:

Made these after work today. blink aluminum 7075 Photo




So sick!!

|

12/11/2017 7:18 AM

Bachmx468 wrote:

Made these after work today. blink aluminum 7075 Photo




If the dimensions on my rm 125 are the same would you be interested in making another set?

|

Tony Alessi, "I think it's time to have more kids so I can have hopes of actually raising a champion."

12/12/2017 11:29 AM

Sixeightone wrote:

If the dimensions on my rm 125 are the same would you be interested in making another set?

I'm from Denmark so I think postage will be expensive

|

12/12/2017 11:54 AM
Edited Date/Time: 12/12/2017 11:55 AM

Some of the titanium bolts arrived todayPhoto



|

12/12/2017 11:56 AM


|

12/12/2017 1:25 PM

Bachmx468 wrote:

Some of the titanium bolts arrived todayPhoto



I’ll PM you my address and please feel free to forward any left over Ti lol I’m excited to see how build develops.

|

12/14/2017 5:49 AM

VERY NICE build! Congratulations!

|

12/15/2017 7:37 AM
Edited Date/Time: 12/15/2017 10:00 AM

Bachmx468 wrote:

Not much progress. New oversized front rotor and crf style mastercylinder. Much better braking and lever feeling. Still a lot to do before its finished


One question does the Kawasaki braking line actulley fit the Honda mastercylinder or did you buy more stuff to make it fit, Im lookin for the same thing for My Kxf.

|

12/17/2017 4:58 AM
Edited Date/Time: 12/17/2017 9:04 PM

Yes, the Kawasaki brake line fits the Honda master cylinder. I bent the end of the brake line a little to get more room between the bars and the brake line

|

2/4/2018 10:27 AM

I would like to try some triple clamps with diffrent offset. It looks like 21.5mm is the preferred offset on the Kx 250. Its hard to find clamps with 21,5mm offset but I can get some cheap Oem triple clamps from a Kawasaki Kxf250 2011. I think the Kxf 250 2011 had 22.5mm offset? Does any of you know if the 22.5mm offset will make the bike handle better or is it a waste of time adapting them to the Kx 250 2stroke

|

2/4/2018 5:30 PM

Get some 2002 clamps. Several have said they work.

|

2/5/2018 10:53 AM

I don't really like the look of the 2002 clamps, and i don't think the front numberplate and fender fits the 2002 clamps smile

|

2/8/2018 3:40 PM

First world problems. Congratulations.

|

2/9/2018 7:07 PM

Are 21.5mm offset clamps still available from RG3 ? Maybe see if they can help you, I think applied used to make them as well maybe somebody knows if they still do.

|

2/17/2018 10:54 AM


|

2/17/2018 11:11 AM

Got some blue radiator hoses Photo





Could not find a place that sells drilled washers here in Denmark so I had to make them myself.Photo


|

2/18/2018 5:10 AM

Bachmx468 wrote:

Got some blue radiator hoses Photo





Could not find a place that sells drilled washers here in Denmark so I had to make them myself.Photo


Holy smokes! Did you give the washers a chamfer? Wow that is trick!

|

2/19/2018 9:17 AM

Yes all edges chamfered smilePhoto

|

1/6/2019 11:19 AM
Edited Date/Time: 1/6/2019 11:22 AM

Almost a year since I last touched the bike. Last week I started to work on it again. I wanted to try the longer PC link, but I couldn’t find one here in Denmark. had a bit of time after work one day so I decided to make one myself. I made it 3mm longer like the PC link. Material alloy 7075 Photo

|

1/6/2019 7:09 PM
Edited Date/Time: 1/6/2019 7:12 PM

Bought some xtrig clams from a kxf. Removed 1 mm from the top clamp to make my Kx fork tubes fit. Next step is to make a new steering stop. Photo

|

1/7/2019 8:11 AM

What length is the kx shock? Any idea if a newer kxf shock will bolt up? Maybe an rmz shock?

|

4/2/2019 7:01 AM

trickeng.com is located in the US and make a really nice stop for adapting the KXF triple clamps to the steel frame. I picked one up for around $50 Photo

|

4/2/2019 7:04 AM

|
